532nm Green Laser Pointer

532nm Laser Pointer 1-20mW





Specifications:

Model

                                   JGI-532-GP

Wavelength

532nm

Operation Mode

CW TEM00

Output Power

1~20mW

Class

IIIA

Operating Current

<200mA

Operating Voltage

3VDC

Beam Divergence (1/e2, Full Angle)

<1.4mrad

Beam Diameter at the aperture

<1.5mm

Line width

< 0.1nm

Beam roundness

>95%

Dimenssion

Dia.13 x 158mm / Dia.20 x 108mm

Power Source

2 x AAA batteries / 1 x CR2 Li battery

Expect life time

5000 hours

Warranty time

6 months





532nm Laser Pointer 50-100mW

Applications:


Fun and games at night club and discos;
Professional lectures;
Astronomy and star gazing;
Lab experiments.



Specifications:

Model

                                  JGI-532-GP

Output Power

50~100mW

Wavelengths

532nm

Beam diameter

<1.5mm

Operating mode

CW@532nm

Transverse mode

TEM00

Beam Divergence (1/e2, Full Angle)

<2mrad

Line width

< 0.1nm

Operating Voltage

3VDC

Dimension

Dia.13 x 158mm / Dia.20 x 108mm

Beam roundness

>95%

Power Source

2 x AAA batteries / 1 x CR2 Li battery

Expect life time

5000 hours

Warranty time

6 months

532nm Laser Pointer 150-200mW

Applications:


Fun and games at night club and discos;
Professional lectures;
Astronomy and star gazing;
Lab experiments.

Specifications:

Model

                                  JGI-532-GP

Output Power

150~200mW

Wavelengths

532nm

Beam diameter

<1.5mm

Operating mode

CW@532nm

Transverse mode

TEM00

Beam Divergence (1/e2, Full Angle)

<2mrad

Line width

< 0.1nm

Operating Voltage

3VDC

Dimension

Dia.13 x 158mm / Dia.20 x 108mm

Beam roundness

>95%

Power Source

2 x AAA batteries / 1 x CR2 Li battery

Expect life time

5000 hours

Warranty time

6 months



532nm Laser Pointer 250-500mW

Specifications:

Model

                                  JGI-532-GP

Output Power

250~500mW

Wavelengths

532nm

Beam diameter

<1.5mm

Operating mode

CW@532nm

Transverse mode

TEM00

Beam Divergence (1/e2, Full Angle)

<2mrad

Line width

< 0.1nm

Operating Voltage

3VDC

Dimension

Dia.13 x 158mm / Dia.20 x 108mm

Beam roundness

>95%

Power Source

2 x AAA batteries / 1 x CR2 Li battery

Expect life time

5000 hours

Warranty time

6 months



DPSS 532nm Green Laser Holistic

Specifications:

Model

        JGI-532-GWP

Output Power

20-150mW

Wavelengths

532nm

Beam diameter

1.2-1.5mm

Operating mode

CW

Transverse mode

TEM00

Beam divergence (full angle)

<1.5mrad

Switch

push button or constant on/off

Working voltage

AC 90-240V

Size

Dia 50×210mm

Operating temperature:

15℃~35℃

Working current

<1200mA
